9
Chapter 3 Terminal Connection
3.1 Terminals Description
Figure 3-1 VS-AXESS-2ETL Terminal Description
Table-3-1 VS-AXESS-2ETL Terminal Description
No.
VS-AXESS-2ETL
A1
Alarm Input
Alarm Input 2
A2
Grounding
A3
Alarm Input 1
B1
Door 2
Door Lock Relay Output (Dry Contact)
B2
B3
B4
Door Button Input
B5
Grounding
B6
Door Magnetic detector
