6
DOCKING STATION CONFIGURATION (Continued)
Step2
Connect your displays to the Docking Station
DISPLAY1 DISPLAY2
HDMI Cable
(Not Included)
Connect to HDMI Monitor
DisplayPort Cable
(Not Included)
Connect to DisplayPort Monitor
OR
HDMI Cable
(Not Included)
Connect to HDMI Monitor
DisplayPort Cable
(Not Included)
Connect to DisplayPort Monitor
OR
HDMI DisplayPort HDMI DisplayPort
