VisionTrack VT1000 - Functions; LEDs & Buzzer Specification

9
FUNCTIONS
G‐SensorCalibration
1. Installtheunitandparkthevehicleonaflatsurface.
2. Turnontheunitandpressthebluebuttononetime.
3. Thencalibrationwillbedonewith“beep”sound.
Built‐inpowerbackup(SuperCapacitor)
Whenpowertotheunitisinterrupted,VT1000createsthelast
fileusingtheinternalSuperCapacitor.
TimeandDate
TherearenotimeanddatesettingsastheVT1000getsthisinformationfromthe
GPSsatellites.
SDMemoryCardFormat
Pleaseformat[initialize]theSDcardusingthePCviewersoftware.
PoweroffvehicleandtakeoutSDmemorycard
TurnoffthepowerandthenchecktheBLUELEDlight.OncetheLEDlight
isnoton,youcannowsafelyremovetheSDmemorycard.
[SDun‐mount]PresstheBluebuttonfor3secondsandreleaseit,thentheBlue
LEDwillstayonallthetime.NowyoucantakeouttheSDmemorycard.
[SDreset]PresstheBluebuttonfor3secondsandreleaseitafterinsertingthe
SDcard,thentheVT1000willreboot.
TakeoutandInsertSDmemorycardduringpoweron
Thereare2waystoremovetheSDcard,thefirstrequiresthevehicletobepowered
downandthesecondyoucansafelyremovetheSDwiththevehicleispoweredon.
Pleaseseebelowdetailsforbothmethods.
SafelyRemovalSDCard
10
Status BLUELED REDLED BUZZER
Booting on on off
Upgrade heartbeat heartbeat off
Continuous recording 4sec / 1sec off off
Triggered
Event recording
0.5sec on/off off 100msec on
SD fault off 0.5 sec on/off off
System fault on on off
SD umount on off 0.1sec on 2 times
SD reset on off 0.1sec on 2 times
SD Full off 2sec / 2sec off
G‐Sensor calibration ‐ ‐ 0.1sec on 1 time
Parking Mode 8sec / 1sec off off
Power off off off off
BLUELED(RECORD)
TheblueLEDshowsthepowerison.
Duringthecontinuousrecording:blueLEDwillbeon4secondsandoff1second.
Duringtheeventrecording:blueLEDwillbeon0.5secondandoff0.5second.
DuringtheParkingmode:blueLEDwillbeon8secondsandoff1second.
REDLED(WarningLED)
TheredLEDwillbeturnedonwhensystemfailure.
Buzzer
A‘Beep’soundwilloccurwheneventrecordingstarts(thiscanbeturnedoff,if
requiredbyuncheck“EventBeep”atSettings)
LEDs&BUZZERSpecification
9 10
LEDS & BUZZER SPECIFICATIONFUNCTIONS
