NOTE: The LDX-80 Camera must have up to date Grass Valley firmware installed (version
22 or greater).
Connector
4-Pin XLR Plug
Pin
Signal
1
GND
2
NC
3
NC
4
+12V
 BNC 75Ω
 BNC 75Ω
 BNC 75Ω
Connector
3-Pin XLR Socket
Pin
Signal
1
GND
2
Hot+
3
Cold-
Connector
5-Pin, 1-Key LEMO Socket
Pin
Signal
1
GND
2
+12V
3
Tally
4
NC
5
NC
Connector
3-Pin Binder Socket
Pin
Signal
1
Data
2
NC
3
GND
