Vislink Lynx L2174 User Manual

Document: CL140072 L2174 Manual Issue 2.0 Page 8 of 26
• Video over IP connection (Ethernet RJ45)
• IP control connection (Ethernet RJ45)
• L1255 Camera Control Transmitter connection. Not active in L2074
5.4 Physical
! CAUTION : the side ventilation grilles must be kept clear to allow adequate airflow.
Size
Height 44mm, Width 210mm, Depth 375mm - including rear panel connectors
Small form 1U, ½ width 19” rack mount
Weight
~1.2kg
Operating temperature range
Ambient 0ºC to +50ºC
Power
AC input option 90 VAC to 264 VAC 50Hz to 60Hz; max current 1A(rms)
DC input option 9 VDC to 36 VDC (-ve chassis earth); max current 10A
70Watts excluding the downconverters requirements.
90Watts max allowing for downconverters and cables.
(
L2170 - 45W; L2074 - 30W, not including downconverters)
