2 D-3645-EPS
4.2 Testing the Unit
Before testing, set DIP switches SW3 and SW4 as required for
the particular application (Para. 4.1).
A. Insert the battery between the battery clips, at the correct
polarity. For proper operation, only Lithium battery
(Panasonic type CR-2 or equivalent) should be used.
B. Press the tamper switch once and release it.
Note: Since the cover is removed and power is applied, a
tamper situation exists. Verify that the MCT-550 transmits
(the LED lights briefly) once every 3 minutes, regardless of
SW4 setting.
C. When you are satisfied that tamper alerts are transmitted
properly, put the cover on to return the tamper switch to its
normal (undisturbed) position. Wait slightly over 3 minutes to
verify that tamper transmissions cease. If all went well, secure
the front cover to the base with the case closure screw.
D. Thoroughly clean the flood sensor with a rag. Bring the flood
sensor into contact with water and verify that the transmitter
LED lights, indicating that transmission is in progress. If SW4
is ON, wait 3 minutes to verify that the transmission is
repeated at 3-minute intervals.
E. Dry the flood sensor using either blotting paper or a rag, thus
restoring it to the undisturbed state and observe the LED. If
SW3 is set to ON, a “restore” transmission will now take place.
F. Refer to the target receiver’s installation instructions, and let
the receiver “learn” the ID code associated with the detector.
4.3 Maintenance
To ensure proper detector's operation, once a month thoroughly
clean the flood sensor with a rag and perform test (see par. 4.2D).
5. MISCELLANEOUS COMMENTS
Visonic Ltd. wireless systems are very reliable and are tested to
high standards. However, due to low transmitting power and
limited range (required by FCC and other regulatory authorities),
there are some limitations to be considered:
A. Receivers may be blocked by radio signals occurring on or
near their operating frequencies, regardless of the digital code
used.
B. A receiver responds only to one transmitted signal at a time.
C. Wireless devices should be tested regularly to determine whether
there are sources of interference and to protect against faults.
The user is cautioned that changes or modifications to the
unit, not expressly approved by Visonic Ltd., could void the
user’s FCC or other authority to operate the equipment.
W.E.E.E. Product Recycling Declaration
For information regarding the recycling of this product you must contact
the company from which you orignially purchased it. If you are discarding
this product and not returning it for repair then you must ensure that it is
returned as identified by your supplier. This product is not to be thrown
away with everyday waste.
European Directive 2002/96/EC Waste Electrical and Electronic Equipment.
WARRANTY
Visonic Limited (the “Manufacturer") warrants this product only (the "Product") to the original purchaser only (the
“Purchaser”) against defective workmanship and materials under normal use of the Product for a period of twelve
(12) months from the date of shipment by the Manufacturer.
This Warranty is absolutely conditional upon the Product having been properly installed, maintained and operated
under conditions of normal use in accordance with the Manufacturers recommended installation and operation
instructions. Products which have become defective for any other reason, according to the Manufacturers
discretion, such as improper installation, failure to follow recommended installation and operational instructions,
neglect, willful damage, misuse or vandalism, accidental damage, alteration or tampering, or repair by anyone
other than the manufacturer, are not covered by this Warranty.
The Manufacturer does not represent that this Product may not be compromised and/or circumvented or that the
Product will prevent any death and/or personal injury and/or damage to property resulting from burglary, robbery,
fire or otherwise, or that the Product will in all cases provide adequate warning or protection. The Product,
properly installed and maintained, only reduces the risk of such events without warning and it is not a guarantee
or insurance that such events will not occur.
THIS WARRANTY IS EXCLUSIVE AND EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES,
OBLIGATIONS OR LIABILITIES, WHETHER WRITTEN, ORAL, EXPRESS OR IMPLIED, INCLUDING ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, OR OTHERWISE. IN
NO CASE SHALL THE MANUFACTURER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES FOR BREACH OF THIS WARRANTY OR ANY OTHER WARRANTIES
WHATSOEVER, AS AFORESAID.
THE MANUFACTURER SHALL IN NO EVENT BE LIABLE FOR ANY SPECIAL, INDIRECT, INCIDENTAL,
CONSEQUENTIAL OR PUNITIVE DAMAGES OR FOR LOSS, DAMAGE, OR EXPENSE, INCLUDING LOSS
OF USE, PROFITS, REVENUE, OR GOODWILL, DIRECTLY OR INDIRECTLY ARISING FROM
PURCHASER’S USE OR INABILITY TO USE THE PRODUCT, OR FOR LOSS OR DESTRUCTION OF
OTHER PROPERTY OR FROM ANY OTHER CAUSE, EVEN IF MANUFACTURER HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGE.
THE MANUFACTURER SHALL HAVE NO LIABILITY FOR ANY DEATH, PERSONAL AND/OR BODILY
INJURY AND/OR DAMAGE TO PROPERTY OR OTHER LOSS WHETHER DIRECT, INDIRECT, INCIDENTAL,
CONSEQUENTIAL OR OTHERWISE, BASED ON A CLAIM THAT THE PRODUCT FAILED TO FUNCTION.
However, if the Manufacturer is held liable, whether directly or indirectly, for any loss or damage arising under this
limited warranty, THE MANUFACTURER'S MAXIMUM LIABILITY (IF ANY) SHALL NOT IN ANY CASE
EXCEED THE PURCHASE PRICE OF THE PRODUCT, which shall be fixed as liquidated damages and not as a
penalty, and shall be the complete and exclusive remedy against the Manufacturer.
When accepting the delivery of the Product, the Purchaser agrees to the said conditions of sale and warranty and
he recognizes having been informed of.
Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so these
limitations may not apply under certain circumstances.
The Manufacturer shall be under no liability whatsoever arising out of the corruption and/or malfunctioning of any
telecommunication or electronic equipment or any programs.
The Manufacturers obligations under this Warranty are limited solely to repair and/or replace at the
Manufacturer’s discretion any Product or part thereof that may prove defective. Any repair and/or replacement
shall not extend the original Warranty period. The Manufacturer shall not be responsible for dismantling and/or
reinstallation costs. To exercise this Warranty the Product must be returned to the Manufacturer freight pre-paid
and insured. All freight and insurance costs are the responsibility of the Purchaser and are not included in this
Warranty.
This warranty shall not be modified, varied or extended, and the Manufacturer does not authorize any person to
act on its behalf in the modification, variation or extension of this warranty. This warranty shall apply to the
Product only. All products, accessories or attachments of others used in conjunction with the Product, including
batteries, shall be covered solely by their own warranty, if any. The Manufacturer shall not be liable for any
damage or loss whatsoever, whether directly, indirectly, incidentally, consequentially or otherwise, caused by the
malfunction of the Product due to products, accessories, or attachments of others, including batteries, used in
conjunction with the Products. This Warranty is exclusive to the original Purchaser and is not assignable.
This Warranty is in addition to and does not affect your legal rights. Any provision in this warranty which is
contrary to the Law in the state or country were the Product is supplied shall not apply.
Warning:
The user must follow the Manufacturer’s installation and operational instructions including testing the
Product and its whole system at least once a week and to take all necessary precautions for his/her safety and
the protection of his/her property.
1/08
ESPAÑOL
1. INTRODUCCION
El MCT-550 es un detector de inundación PowerCode, de
interior, y totalmente supervisado, utilizado para detectar la
presencia de líquidos con contenido de agua en cualquier
lugar que se desee.
El transmisor MCT-550 está diseñado para montaje en pared. El
sensor de inundación deberá estar situado en una posición
donde sea probable la presencia de agua, como resultado de la
filtración o inundación.
Tras la detección de inundación, se transmite un mensaje
digital,
que se compone del ID PowerCode del detector seguido por varios
códigos de estado
y otros mensajes. La alarma y demás datos
serán remitidos al sistema de alarma.
Cuando se quita la tapa, un tamper incorporado se abre. En
situación de tamper, se transmite un mensaje de tamper.
Un mensaje de supervisión periódico se transmite de forma
automática (ver especificaciones) para informar al sistema de
alarma a intervalos regulares de la activa participación de la
unidad en el sistema.
El LED luce siempre que se informa de un evento de alarma o
tamper. El LED no luce mientras que un mensaje de supervisión se
esté transmitiendo.
La alimentación de funcionamiento se obtiene de una pila de 3V
de litio incorporada. En caso de baja tensión de la pila provocará
un informe “pila baja” que será añadido a cualquier mensaje
transmitido.
2. ESPECIFICACIONES
Compatibilidad: Compatible con los sistemas PowerMax y
PowerMax+, receptor MCR-308 o cualquier otro sistema de
alarma PowerCode.
Frequencia (MHz): 315, 433.92, 868.95, 869.2625 u otra
frecuencia de acuerdo a los requerimientos locales.
Código de identificación del transmisor: Palabra digital de 24-
bits, sobre 16 millones de combinaciones, modulación del ancho
del pulso.
Longitud total del mensaje: 36 bits
Repetición del mensaje: Una sola transmisión (por defecto) o
una vez cada 3 minutos (seleccionable).
Supervisión: Señalización a intervalos de 60 minutos (versión
U.S.) o a intervalos de 15 minutos (versión UK), o de acuerdo a
los estándares locales.
Respuesta a Evento de Tamper: Informe de tamper cada 3
minutos (hasta que el tamper sea restaurado).
Fuente de alimentación: Pila de 3V de litio, tipo Panasonic CR-2
o equivalente.
Capacidad nominal de la pila: 750 mAh
Consumo de corriente: 6µA en reposo, 17mA de promedio en
funcionamiento (incluyendo el LED).
Vida de la pila con LED encendido: 3 años (para uso típico)
Supervisión de la pila: Informe automático del estado de la pila
como parte de los datos de toda transmisión.
