5.2. Replacing the Battery
Replace the battery at least once every 5 years, or upon observing
that the LED flickers when transmitting. The required battery is
CR2032 Lithium 3V, manufactured by VARTA or another UL-
recognized manufacturer, purchased from a Visonic- approved
supplier.
Note: The polarity of the battery must be observed, as shown in
Figure 7. Improper handling of lithium batteries may result in heat
generation, explosion or fire, which may lead to personal injuries.
Warning! Danger of explosion if batteries are installed
incorrectly. Replace only with the same or equivalent type
recommended by the manufacturer. Keep away from small
children. If batteries are swallowed, promptly see a doctor. Do not
try to recharge these batteries. Disposal of used batteries must be
made in accordance with the waste recovery and recycling
regulations in your area.
1. Insert a coin into the slot on the bottom center of the device
and twist to separate the two sides.
2. Then, slide the coin to the corner of the device and twist
again to remove the cover.
Figure 6. Opening the PB-101/102
Note: Make sure the elastic pad within the cover remains in place.
Put it back in place if it falls off.
Figure 7. Replacing the Battery
3. Extract the old battery from its holder, and replace it with a
recommended new battery. Ensure that the plus side of the
battery faces up, attaining correct polarity.
4. Test the unit by momentarily pressing one of the transmit
switches. The LED indicator should light.
5. Put the covers back on securely, verifying that it snaps shut.
5.3. Cleaning
The pendant may get dirty if touched with greasy fingers. Clean it
only with a soft cloth or sponge moistened lightly with a mixture of
water and mild detergent, and wipe it dry immediately.
The use of abrasives of any kind is strictly forbidden. Also never
use solvents such as kerosene, acetone or thinner.
Do not submerge this product in any liquid, in order to prevent
damage to the electronic circuits.
6. PRODUCT LIMITATIONS
Visonic wireless systems are very reliable and are tested to high standards. However, due to their low transmitting power and limited range (required by
FCC and other regulatory authorities), there are some limitations to be considered:
A. Receivers may be blocked by radio signals occurring on or near their operating frequencies, regardless of the code selected.
B. A receiver can only respond to one transmitted signal at a time.
C. Wireless equipment should be tested regularly to determine whether there are sources of interference and to protect against faults.
Frequency Allocations for Wireless Devices in European (EU) Countries
433.92 MHz has no restriction in any EU member state.
7. COMPLIANCE WITH STANDARDS
The PB-101/102 PG2 complies with the following standards:
Europe: EN 300220, EN 301489 EN 50130-4, EN 50130-5, EN 60950-1, EN-50131-3 and EN-50131-6 Type C.
Hereby, Visonic Ltd. declares that the radio equipment type PB101/102 PG2 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address:
http://www.visonic.com/download-center.
EN 50131-1 Security Grade: According to EN 50131-1 this equipment can be applied in installed systems up to and including Security
Grade 2.
EN 50131-1 Environmental Class: Class II
Certified by Applica Test & Certification AS in accordance with EN 50131-3, EN 50131-6, EN 50131-4, EN 50131-5.
D-304457 PB-101 PG2 / PB-102 PG2 Installation Instructions 3
