QR254 (SERIES) 12
ENGLISH
Installation (continued)
Align the bracket against the side edge of the 30 in
(762 mm) cabinet cabinet and the back wall. Draw a line
DORQJLQQHUHGJHRIWKHEUDFNHWDVVKRZQLQŵJ
Slide the bracket inwards and align it against the marked
line. Ensure the rear edge is tight against wall as shown
LQŵJ
Use a pencil to mark the location of the 3 center holes as
VKRZQLQŵJ
Set the bracket aside and drill three 7/64” holes in the
PDUNHGORFDWLRQVDVVKRZQLQŵJ
Secure the bracket to the cabinet using a Phillips
screwdriver and 3 supplied countersunk wood screws
((DVVKRZQLQŵJ
5HSHDWWKHDERYHSURFHGXUHWRLQVWDOOWKHUHPDLQLQJŶDW
bracket on the opposite side of the cabinet.
7/64”
Fig. 17-1
Fig. 17-2
Fig. 17-3
Fig. 17-4
EE
15 in
(381 mm)
Center Line
