Pre-Installation
TOOLS REQUIRED
Phillips
screwdriver
Measuring tape
or ruler
Flat blade
screwdriver
Scissors or knife
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
TIMER
ON
TIMER
OFF
TEMP
LED
ON/OFF
SHORT
CUT
MODE
FAN
SLEEP SWING
AA
BB
CC
DD
EE
FF
GG
HH
II
JJ
KK
LL
Part Description Quantity
AA Unit Adaptor 1
BB Exhaust Hose 1
CC Window Slider Adaptor 1
DD Foam Seal B (Adhesive) 2
EE Foam Seal C (Non-adhesive) 1
FF Security Bracket and 2 Screws 1
GG Window Slider A 1
HH Window Slider B 1
II Foam Seal A (Adhesive) 2
JJ Drain Hose 1
KK Bolt 1
LL Remote Control and Batteries
(only for remote control models)
1
