6
Pre-Installation (continued)
PACKAGE CONTENTS
A
Front
B
C
D
E
F
Rear
G
H
I
J
K
L
M
Part Description
A Control Panel
B Remote Signal Receptor
C Horizontal Louver Control
D Vertical Louver Control
E Panel
F Caster
G Handle (both sides)
H Air Filter
I Upper Air Intake
J Drain Outlet
K Air Outlet
L Lower Air Intake
M Bottom Tray Drain Outlet
