1. Getting to know your camcorder
1.1 Configuration and installation
1：Lens
2: Microphone
3: Compensating lamp
4: Self-Timer LED
5: Delete
6: Playback
7: Mode
8: TFT LCD Screen
9: Left
/Self-Timer
10: Power
11: Down button
12: Menu
13: AV Out jack
14: USB jack
15: Right
/LED on or off
16: OK
17: Shutter
18: Up
/Display
19: W/Zoom in button
20: T/Zoom out button
21: Speaker
22: Tripod socket
23: Card slot
24: Battery cover
