PAGE 6
W IRE YOUR SPA PER ONE OF THE DI A GRA MS MO ST SIMILAR TO YOUR
HOUSE PA NEL
ALL WIRES FEEDING THE SPA ARE TO BE THE SAME GAUGE. GROUND WIRES ARE
TO BE INSULATED AS WELL. WHEN USING A GROUND ROD, THE GROUND WIRE
TO THE ROD SHOULD BE #6 BARE COPPER.
ALL SPAS REQUIRE THE USE OF AN ISOLATED GFCI PROTECTED CIRCUIT. THE
INSTALLATION OF A DISCONNECT IS REQUIRED NO MORE THAN TEN (10) VISUAL
FEET FROM THE SPA AND NOT LESS THAN FIVE (5) FEET.
THIS REQUIREMENT IS TO ASSURE THAT WHEN POWER IS DISCONNECTED FROM
THE SPA, POWER CAN NOT BE INADVERTENTLY TURNED BACK ON.
EL E C T R ICAL RE QUIREMEN TS AND INSTA L LAT ION
S E PA RATE NE U T RAL & SO L ID
G R O UND
