vitalconnect
vitalconnect
Prepare Skin
1
Remove from Pouch and Power On
2
Hold Against Chest
3
vitalconnect
vitalconnect
Press and release
power button.
Green light
flashes once.
OR
Primary Site
Secondary Site
Left Side
Primary
Site
Secondary
Site
Space patch two
fingers below the
jugular notch.
Position logo near
midline and angle
patch down.
Position patch
horizontally with
logo near
midline.
Logo
Logo
Two Fingers
Left
Hand
Left
Hand
Apply VitalPatch Biosensor
Choose either the Primary Site on your
upper left chest (preferred) or the
Secondary Site on the lower left chest on
the rib cage.
Clean site with an alcohol pad and allow
to dry. If there is body hair, shave the site
before cleaning.
Jugular Notch
Tear
3
Midline
Midline
To Next Page
