Vitamix S30 - Parts and Features; Component Identification

PARTS AND FEATURES
0.6 L (20 ounce) Container
(top rack dishwasher safe,
DO NOT use in a microwave)
Pulse Feature
is to the le of the stop position
on the Variable-speed Control
Variable-speed Control
is used to select blade speed
from 1 to 10 (low to high)
Tamper
is used to maintain circulation by preventing
air pockets in the 1.2 L (40 ounce) container.
See page 11.
(top rack dishwasher safe)
Spill-Proof Vented Lid
with removable lid plug
(top rack dishwasher safe,
DO NOT use in a microwave)
1.2 L (40 ounce) Container
shatter-resistant container
(top rack dishwasher safe,
DO NOT use in a microwave)
Seals
Two seals are supplied with your
blender. Refer to page 9 for more
information about seals.
Interchangeable Blade Base
is used to blend in with the 0.6 L (20 ounce)
and 1.2 L (40 ounce) containers
(top rack dishwasher safe, DO NOT use in a
microwave)
Overow Opening
is located on the back
of the motor base. It
directs liquid away
from the motor in
case of a leak. If you
experience leaks, refer
to Tips and Techniques
on page 9.
Flip-Top Lid
The seal MUST be in place to
avoid leaks when using the
0.6 L (20 ounce) container as
a to-go cup.
(top rack dishwasher safe,
DO NOT use in a microwave)
Interlock Tab
Both containers have two
interlock tabs that must be
positioned in the cut-outs in
the motor base for the motor
to operate.
Motor Base
(top rack dishwasher safe,
DO NOT use in a microwave)
7
