5.3 Pipe length and the elevation
The pipe length and refrigerant amount:
Model
Pipe size
Standard
length
Max.
Elevation
Max.
Length
Additiona
l
Gas
Liquid
ACP-09CH25AERO/I+ ACP-09CH25AERO
/O
3/8’’
(Ф9.52)
1/4’’
(Ф6.35)
5 8 20
20
ACP-12CH35AERO/I + ACP-12CH35AERO/
O
1/
2’’
(Ф12.7)
1/4’’
(Ф6.35)
5 8 20
20
A
CP-12CH35AEXO/I + ACP-12CH35AEX
O/O
A
CP-18CH50AERO/I + ACP-18CH50AER
O/O
1/
2’’
(Ф12.7)
1/4’’
(Ф6.35)
5 10 25
20
A
CP-24CH70AERO/I + ACP-24CH70AER
O/O
5
/8’’
(Ф15.9)
3/8’’
(Ф9.52)
5 10 25
40
Caution:
The capacity test is based on the standard length and the maximum permissive length is based on the
system reliability.
