5. Installation details

5.1 Wrench torque sheet for installation

Outside diameter Torque

Additional

tightening torque

inch

N.cm

Ф6.35

1/4

1500(153kgf.cm)

1600(163kgf.cm)

Ф9.52

3/8

2500(255kgf.cm)

2600(265kgf.cm)

Ф12.7

1/2

3500(357kgf.cm)

3600(367kgf.cm)

Ф15.9

5/8

4500(459kgf.cm)

4700(479kgf.cm)

Ф19

3/4

6500(663kgf.cm)

6700(683kgf.cm)

5.2 Connecting the cables

The power cord of connect should be selected according to the following specifications sheet.

Rated current of appliance Nominal cross-sectional area (mm²)

>3 and ≤6

0.75

>6 and ≤10

1.0

>10 and ≤16

1.5

>16 and ≤25 2.5

The cable size and the current of the fuse or switch are determined by the maximum current indicated on

the nameplate which located on the side panel of the unit. Please refer to the nameplate before selecting

the cable, fuse and switch.
