Vivax ACP-12CC35AECI User Manual

The Specification of Power
20 Indoor Units
9. The Specification of Power
Model 18000-24000Btu/h 30000 Btu/h 36000 Btu/h 36000 Btu/h
INDOOR UNIT
POWER
Phase 1-phase 1-phase 1-phase 1-phase
Frequency and
Voltage
220-240V, 50Hz 220-240V, 50Hz 220-240V, 50Hz 220-240V, 50Hz
POWER WIRING
(mm
2
)
3×1.0 3×1.0 3×1.0 3×1.0
CIRCUIT BREAKER
/ Fuse (A)
15/10 15/10 15/10 15/10
OUTDOOR UNIT
POWER
Phase 1-phase 1-phase 1-phase 3-phase
Frequency and
Voltage
220-240V, 50Hz 220-240V, 50Hz 220-240V, 50Hz 380-420V, 50Hz
POWER WIRING
(mm2)
3×2.5 3×2.5 3×4.0 5×2.5
CIRCUIT BREAKER
/ Fuse (A)
30/20 40/30 40/30 30/20
Indoor/Outdoor Connecting Wiring
(Weak Electric Signal) (mm
2
)
2×0.2 2×0.2
2×0.2 2×0.2
Indoor/Outdoor Connecting Wiring
(Strong Electric Signal) (mm
2
)
Model(Btu/h) 48000 42000-60000
INDOOR UNIT
POWER
Phase 1-phase 1-phase
Frequency and
Voltage
220-240V, 50Hz 220-240V, 50Hz
Power Wiring
(mm
2
)
3×1.0 3×1.0
Circuit Breaker/Fuse
(A)
15/10 15/10
OUTDOOR UNIT
POWER
Phase 1-phase 3-phase
Frequency and
Voltage
220-240V, 50Hz 380-415V, 50Hz
Power Wiring
(mm
2
)
3×4.0 5×2.5
Circuit Breaker/Fuse
(A)
40/35 30/25
Indoor/Outdoor Connecting Wiring
(Weak Electric Signal) (mm
2
)
2×0.2
2×0.2
Indoor/Outdoor Connecting Wiring
(Strong Electric Signal) (mm
2
)

Vivax ACP-12CC35AECI Specifications

General

Brand	Vivax
Model	ACP-12CC35AECI
Category	Air Conditioner
Language	English
