Vivax ACP-12PT35AEF User Manual

ENG VIVAX
37
Installation instructions:
Exhaust hose installation:
The exhaust hose and adaptor must be installed or removed in accordance
with the usage mode.
COOL, HEAT (heat pump type) or AUTO
mode
Install
FAN,DEHUMIDIIFY or HEAT (electrical heat type) mode
Remove
1. Install the adaptor B and adaptor I onto the exhaust hose as shown in
Fig.16a or Fig.16b. Refer to the previous pages for window kit
installation.
2. Resert the hook of the Exhaust hose into the hole seat of the air outlet
and slide down the Exhaust hose along the arrow direction (See
Fig.17) for installation.
Fig.16a
Fig.16b
Fig.17
Hole seatl
Hook

Vivax ACP-12PT35AEF Specifications

General

Type	Monobloc mobile air conditioner
Noise level	65 dB
Refrigerating medium	R410A
Dehumidifier function	Yes
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.2 l/h
Air conditioner functions	Cooling
Heating capacity in watts (max)	- W
Cooling capacity in watts (nominal)	3500 W
Heating capacity in watts (nominal)	0 W
Cooling energy efficiency (EER, W/W)	2.61
Heating energy efficiency (COP, W/W)	0
Energy efficiency scale	A+++ to D
Power consumption (cooling)	1350 W
Energy efficiency class (heating)	A
Hourly energy consumption (cooling)	1.4 kWh
Hourly energy consumption (heating)	- kWh
Product color	White

Weight and Dimensions

Depth	- mm
Weight	- g
