Vivotek CC8160 - Page 334

VIVOTEK
334 - User's Manual
Technical Specications
Technical Specifications
Model CC8160
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.9" Progressive CMOS
Maximum Resolution 1920x1080
Lens Type Fixed-focal
Focal Length f = 1.66 mm
Aperture F1.95
Field of View
180° (Horizontal)
100° (Vertical)
180° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Enhanced
Minimum Illumination 0.22 Lux @ F1.95 (Color)
Tilt Range 15 degrees with bracket
Pan/Tilt/Zoom
Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in, 12x
built in)
Video
Compression H.264 & MJPEG
Maximum Frame Rate
H.264: 30 fps @ 1920x1080
MJPEG: 30 fps @ 1920x1080
Maximum Streams 4 simultaneous streams
S/N Ratio 58.2 dB
Dynamic Range 50.6 dB
Video Streaming
Adjustable resolution, quality and bitrate
Smart Stream II
Image Settings
Adjustable image size, quality and bit rate
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast,
saturation, sharpness, white balance,
exposure control, gain, backlight
compensation, privacy masks
Scheduled profile settings
Audio
Audio Capability One-way audio
Compression G.711, G.726
Interface Built-in Microphone
Effective Range 5 meters
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP,
RT SP/RTP/ R TCP, I G M P, SM T P, F TP, D H C P,
NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP,
802.1X , NTCIP
Interface
10 Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard
CAT5e & CAT6 cables which are compliant
with the 3P/ETL standard.
ONVIF
Supported, specification available at www.
onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
VCA
Line crossing detection, field detection,
loitering detection
*Available per project request
Alarm and Event
Alarm Triggers
Motion detection, manual trigger,
periodical trigger, system boot, recording
notification, camera tampering detection,
audio detection
Alarm Events
Event notification using HTTP, SMTP, FTP
and NAS server
File upload via HTTP, SMTP, FTP and NAS
server
General
Connectors RJ-45 for Network/PoE connection
LED Indicator System power and status indicator
Power Input IEEE 802.3af PoE Class 2
Power Consumption Max. 2.01 W
Dimensions
28 mm (D) x 50 mm (W) x 88 mm (H)
(Body only)
40 mm (D) x 58 mm(W) x 127 mm (H)
(Tilt Mount)
Weight Net: 66.7 g
Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Humidity 90%
Warranty 24 months
System Requirements
Operating System Microsoft Windows 7/Vista/XP/2000/8
Web Browser
Mozilla Firefox 7~43 (streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
Others
Quick installation guide, warranty card,
camera stand, screw pack
Dimensions
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 4
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. | T: +886-2-82455282 | F: +886-2-82455532 | E: sales@vivotek.com | W: www.vivotek.com
36 mm
58 mm
50 mm
127 mm
134 mm
40 mm
88 mm
