VIVOTEK
User's Manual - 51
Please follow the steps below to set up a prole:
1. Select the Prole mode tab.
2. Select the applicable mode: Night mode or Schedule
mode. Please manually enter a range of time if you
choose the Schedule mode.
3. Congure Exposure control settings in the folowing
columns. Please refer to previous dicussions for
detailed information.
4. Click Save to enable the setting and click Close to
exit the page.
You can click Restore to recall the original settings without incorporating the changes. When completed
with the settings on this page, click Save to enable the settings.
If you want to congure another sensor setting for day/night/schedule mode, please click Prole to open
the Prole of exposure settings page as shown below.
Activated period:
Select the mode this profile to apply to: Day mode, Night mode, or Schedule mode.
Please manually enter a range of time if you choose Schedule mode. Then check Save to take effect.
Enable WDR enhanced: This function allows users to identify more image details with an extreme
contrast from an object of interest with one shadowed side against a bright background, e.g., an entrance.
You may select the Enable WDR enhanced checkbox, and then adjust the strength (low, medium, high)
to reach the best image quality.
■
AE Speed Adjustment:
This function (Automatic Exposure) applies when you need to monitor fast changing lighting conditions.
For example, the camera may need to monitor a highway lane or entrance of a parking area at night
where cars passing by with their lights on can bring fast changes in light levels. The same applies if
the camera is installed on a vehicle, and when it needs to adapt to fast changes of light when entering
and leaving a tunnel. The speed level and sensitivity can be manually adjusted.
