EN - 3
English
Tilt Screw
SD Card
Slot
IR LEDs
Reccessed Reset Button
N.C.
N.C.
N.C.
AC24V
AC24V
Focus Controller
Zoom Controller
Image Adjustment
Screw
Status LED
Light Sensor
Physical Description
2
Pan Screw
Lens
Inner View
Ethernet 10/100 RJ45 Plug
Audio Out (green)
Microphone In (pink)
Power Cord Socket (black)
General I/O Terminal
Block
Ground
Fan
The fan will operate when the
temparature inside the Network
Camera reaches over 50°C.
f= 3.3~12 mm (FD7141 Lens)
f= 9~22 mm (FD7141V Lens)
