EN - 4
Hardware Installation
3
Physical Description
2
Lens
IR LEDs (8 units, distance 10m)
(FD8134V only)
Reset Button
General I/O Terminal Block
Status LED
Light Sensor
MicroSD/SDHC
Card Slot
Black Cover
Ethernet 10/100
RJ45 Plug
Power Cord Socket
First, follow the instructions below to remove the dome cover.
Dome Cover
Record the MAC address before
installing the camera.
Network Camera
Model No: FD8134V
Made in Taiwan
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1)This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Pat. 6,930,709
RoHS
V I
MAC:0002D107258A
To Next Page
