VIVOTEK
User's Manual - 175
is located at the center of full
scene.
videoin_c0_mode1_outputsize <WxH> FD8365:
1920x108
0
FD8355:
1280x102
4
0/7 The output size of source,
equal to the captured size by
device, in this video mode.
The unit is pixel.
This value is used as a basic
coordinate system for many
features, like ePTZ, privacy
mask, motion, etc.
* Source (most for image
sensor) may perform scale or
binning, etc on image data,
and output data with smaller
size. This parameter is
designed to represent this.
videoin_c0_mode1_binning binning 0 0/7 Indicate binning is used or
not in this video mode.
0: No binning
1: 2x2 binning
3: 3x3 binning
videoin_c0_mode1_nresolution <positive
integer>
FD8365:
7
FD8355:
8
0/7 Available resolutions list.
videoin_c0_mode1_resolution <a list of
available
resolution
separated by
commas>
<product
dependent>
FD8365:
176x144,
384x216,
640x360,
1280x720
,
1360x768
,1600x90
4,1920x1
080
FD8355:
176x144,
320x240,
640x480,
0/7 Available resolutions list.
