Vivotek FD8155H Quick Installation Guide

1. DC 12V-
2. DC12V+
3. AC24V_2
4. AC24V_1
5. DI- (GND)
6. DI+
7. DO-
8. DO+ (+12V)
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
2
Physical Description / Beschreibung der Teile / Afmetingen
Light Sensor
Camera Front View
Lichtsensor
Kamera Vorderansicht
Lichtsensor
Voorkant van camera
Vari-focal Lens
Gleitsichtobjektiv
Varifocusknop
IR LEDs (4 units, effective up to
30m)
IR-LEDs (4 Einheiten mit einer
Reichweite von bis zu 30 m)
IR-leds (4 eenheden, effectief
tot 30m)
Focus & Zoom Buttons
Fokus/Zoom-Taste
Focus- en zoomknoppen
Camera Rear View
Kamera Rückseite
Achterkant van camera
NOTE:
The max. output load from pins #7
MicroSD/SDHC/SDXC Card Slot
and 8 is 50mA.
MicroSD/SDHC/SDXC Kartensteckplatz
MicroSD/SDHC/SDXC-aansluiting
Reset Button
Rückstellungsschalter
Resetknop
General I/O Terminal Block
Jumpers
Micro SD Card
Reset Ethernet
12 3 45 678
NTSC
Allgemein E/A
Jumper
AV Out
Audio In
Anschlussleiste
Jumper
PAL
Algemene I/O-terminalblok
Microphone
Video Output
Mikrofon
Videoausgang
Microfoon Video-uitgang
internal
Audio/Video Out
(green)
Intern
NTSC 60Hz
Intern
Audio/Video Ausgang
(Grün)
Ethernet 10/100 RJ45
Audio/video-uit (groen)
Socket
Ethernet 10/100 RJ45
Microphone In (pink)
Buchse
external
Extern
Ethernet 10/100
Mikrofon Eingang (Pink)
PAL
RJ45-aansluiting
Extern
50Hz
Microfoon-in (roze)
1 2
EN - 2
