Outer View
Physical Description
2
Leave the slide cover in place if you route cables through the
bottom and then through a hole on the ceiling or wall.
Release tab
DI+ DI-
Max. is 40V.
Slide cover
Digital input
Lens
Tilt adjustment
screw
Reset button
Screw slot
Inner View
RJ-45 Socket
Side View
MicroSD/SDHC/
SDXC
card slot
