VIVOTEK
User's Manual - 33
Global View: Click on this item to display the Global View window. The Global View window contains a
full view image (the largest frame size of the captured video) and a oating frame (the viewing region of
the current video stream). The oating frame allows users to control the e-PTZ function (Electronic Pan/
Tilt/Zoom). For more information about e-PTZ operation, please refer to E-PTZ Operation on page 102.
For more information about how to set up the viewing region of the current video stream, please refer to
page 102.
The viewing region of
the current video
stream
The largest frame size
PTZ Panel: This Network Camera supports “digital“ (e-PTZ) pan/tilt/zoom control, which allows roaming
a smaller view frame within a large view frame. Please refer to PTZ settiings on page 102 for detailed
information.
NOTE:
1. For a megapixel camera, it is recommended to use monitors of the 24" size or larger, and
are capable of 1600x1200 or better resolutions.
2. The video input is "muted" by default. To receive audio into from external microphone, you
need to enable the audio input from Media > Audio. Refer to page 72 for more information.
3. Below are the defaults for the Audio settings:
For cameras with a built-in microphone: Not Muted.
For cameras without a built-in microphone: Muted.
To receive audio input from an external microphone, you may need to enable the audio input
from Media > Audio. Refer to page 72 for more information.
Quick Time player only supports playback of H.264 stream, and not the MJPEG stream. In terms of audio
codec, Quick Time only supports AAC. Since this camera supports G.711 codec, audio is not available
on Quick Time.
The VLC player supports H.264/MPEG-4/MJPEG, and all audio codecs supported by VIVOTEK’s cam-
eras.
NOTE:
