User's Manual - 69
• Mode:
- Auto: When set to Auto, only the moving objects and the areas around them will be
displayed with the Foreground quality. The rest of the screen will be displayed with
the Background (lower) quality.
- Manual: When selected, the Manual window setting option will be displayed. Click
on it to display the setting window. You can then manually allocate the regions of
your interest on the current eld of view. Click New, drag, and pull the window to
cover the regions of your interest. Note that the title bar on each window is not
taken into account when setting the Foreground areas.
You can create up to 3 ROI windows. Click Save to preserve your setting and click
Close to nish the conguration.
ROI_0
ROI_1
Background
Q= Medium or low
Foreground
Q= Detailed
Foreground
Q= Detailed
