Vivotek FD8167A User Manual

VIVOTEK
320 - User's Manual
Model FD8169A
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.9 Progressive CMOS
Maximum Resolution 1920x1080 (2MP)
Lens Type Fixed-focal
Focal Length f = 2.8 mm
Aperture F1.8
Field of View
105° (Horizontal)
60° (Vertical)
109° (Diagonal)
ShutterTime 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Enhanced
Day/Night RemovableIR-cut filter for day & night function
Minimum Illumination
0.06 Lux @ F1.8 (Color)
0.01 Lux @
F1.8 (B/W)
Pan/Tilt/Zoom Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built-in)
IR Illuminators
Built-in IRilluminators, effective up to 20 meters
with Smart IR
IR LED*8
On-board Storage
MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.264 & MJPEG
Maximum Frame Rate
30 fps @ 1920x1080
In both compression modes
Maximum Streams 4 simultaneous streams
S/N Ratio 68.5 dB
Dynamic Range 69.4 dB
Video Streaming
Adjustable resolution, quality andbitrate
Smart
Stream II
Image Settings
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation,
sharpness, whitebalance, exposure control, gain,
backlight compensation, privacy masks
Scheduled profile settings, 3D noise reduction,
video rotation, defog
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL,
TLS
Interface
10
Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e
& CAT6 cables which are compliant with the 3P/ETL
standard.
Technical Specifications
Compatible Accessories
ONVIF Supported, specification available at www.onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
Alarm and Event
Alarm Triggers
Motiondetection,manual trigger, periodical
trigger, system boot, recordingnotification, camera
tampering detection
Alarm Events
Event notification using HTTP, SMTP, FTP and NAS
server, SD Card
File upload via HTTP, SMTP, FTP, NAS server and SD
card
General
Connectors RJ-45 for Network/PoE connection
LED Indicator System p
ower and status indicator
Power Input IEEE 802.3af PoEClass 0
Power Consumption Max: 8.5 W
Dimensions Ø: 129 mm x 94 mm
Weight Net: 416.4 g
Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick
Operating Temperature
Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F )
Working Temperature: -10°C ~ 50°C (14°F ~ 122°F )
Humidity 90%
Warranty 24 months
System Requirements
Operating System Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~43 (streaming only)
Internet Explorer 7/8/9
/10/11
Other Players
VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
Others
Quick installation guide, alignment sticker,screw
pack
Dimensions
Ø129 mm
94 mm
Mounting Kits
AM-21A
L-shapeBracket
(Coming Soon)
AM-528
Mounting Adapter
AM-51D
Adapter Ring
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 5
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. T: +886-2-82455282 F: +886-2-82455532 E: sales@vivotek.com W: www.vivotek.com
VIVOTEK INC.
