Vivotek FD8169 - Page 154

VIVOTEK
154 - User's Manual
39
0(not support),
1(support)
Bit 1 => Built-in or
external video source;
0(external), 1(built-in)
Bit 2 => Support pan
operation, 0(not
support), 1(support)
Bit 3 => Support tilt
operation; 0(not
support), 1(support)
Bit 4 => Support zoom
operation;
0(not support),
1(support)
Bit 5 => Support focus
operation;
0(not support),
1(support)
Bit 6 => Support iris
operation;
0(not support),
1(support)
Bit 7 => External or
built-in PT; 0(built-in),
1(external)
Bit 8 => Invalidate bit 1
~ 7;
0(bit 1 ~ 7 are valid),
1(bit 1 ~ 7 are invalid)
Bit 9 => Reserved bit;
Invalidate lens_pan,
Lens_tilt, lens_zoon,
lens_focus, len_iris.
0(fields are valid),
1(fields are invalid)
Examples:
PT8133: 0b1111
SD8362: 0b111111
VS8102: 0b10111101
