10 - User's Manual
7. Insert the Ethernet cable through the rubber seal. Strip part of the sheath from the
Ethernet cable.
Rubber seal plug
CAT5 wires
Approx. 5 ~ 6
8. Install the rubber seal plug to the cabling hole on the camera. Make sure the top section
of the seal plug is ush with the top of the cabling hole.
