1
2
3
4
5
6
7
8
o: white/orange stripe
O: orange solid
g: white/green stripe
B: blue solid
b: white/blue stripe
G: green solid
br: white/brown stripe
BR: brown solid
9. You will need an RJ45 crimping tool to attach the Ethernet wires to a connector.
10. When done, connect the cable to the camera's RJ45 socket.
