VIVOTEK
User's Manual - 27
•
Currently the Network Camera utilizes a 32-bit ActiveX plugin. You CAN NOT open a
management/view session with the camera using a 64-bit IE browser.
•
If you encounter this problem, try execute the Iexplore.exe program from C:\Windows\
SysWOW64. A 32-bit version of IE browser will be installed.
•
On Windows 7, the 32-bit explorer browser can be accessed from here:
C:\Program Files (x86)\Internet Explorer\iexplore.exe
•
If you open a web session from the Shepherd utility, a 32-bit IE browser will be
opened.
IMPORTANT:
1. The onscreen Java control can malfunction under the following situations: A PC con-
nects to di󰀨erent cameras that are using the same IP address (or the same camera
running di󰀨erent rmware versions). Removing your browser cookies will solve this
problem.
2. If you encounter problems with displaying the conguration menus or UI items, try dis-
able the Compatibility View on IE8 or IE9.
You may also press the F12 key to open the developer tools utility, and then change the
Browser Mode to the genuine IE8 or IE9 mode.
Tips:
In the event of plug-in compatibility issues, you may try to uninstall the plug-in that was
previously installed.

Other manuals for Vivotek FD9369

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek FD9369 and is the answer not in the manual?

Vivotek FD9369 Specifications

General IconGeneral
TypeIP security camera
CertificationCE, FCC, ICES-003, RCM, VCCI, Safety, UL, CB, IA, BIS, IK10, IP66
Placement supportedIndoor & outdoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Yes
Wi-Fi-
Number of users10 user(s)
Streaming methodMulticast
Networking standardsIEEE 802.3af
Ethernet interface typeFast Ethernet
Supported network protocols802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP
Flash memory256 MB
Compatible memory cardsSD, SDHC, SDXC
Ethernet LAN (RJ-45) ports1
Sensor typeCMOS
Optical sensor size1/3.1 \
DC output voltage12
Power source typeDC, PoE
Power consumption (max)6.49 W
Power consumption (typical)4 W
IK codeIK10
Form factorDome
Mounting typeCeiling
Product colorBlack, White
LED indicatorsPower, Status
International Protection (IP) codeIP66
Pan range0 - 350 °
Tilt angle range-10 - 75 °
Camera shutter speed1/5 - 1/32000 s
Minimum illumination0.08 lx
Operating temperature (T-T)-30 - 50 °C
Operating relative humidity (H-H)0 - 95 %
Audio system1-way
Audio formats supportedG.711, G.726
Signal-to-Noise Ratio (SNR)59 dB
Bit rate controlConstant Bit Rate (CBR)
Total megapixels2 MP
Maximum resolution1920 x 1080 pixels
Video formats supportedH.264, H.265, M-JPEG
Image quality adjustmentBrightness, Saturation, Sharpness
LED typeIR
Night vision distance30 m
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Digital zoom18 x
Focal length range2.8 mm
Weight and Dimensions IconWeight and Dimensions
Weight465 g
Diameter110 mm
