VIVOTEK
User's Manual - 7
RJ45
Ethernet port
Some of the sufx syntax used in model naming are listed below:
E w/ heater for extreme weather
Fx Focal length w/ number
T w/ Remote focus lens
R w/ PoE repeater
H w/ High Dynamic Range functionality
NOTE:
Hardware Installation
0002D10766AD
XXXXXX
1
1. Jot down the camera's MAC address for later reference.
IMPORTANT:
The camera comes with an embedded heater and requires an 802.3at PoE switch.
IMPORTANT:
If DC power is preferred, it should comply with: O/P: 12VDC, 1A or 2A min., L.P.S. per IEC
60950-1.
Si l'alimentation CC est préférable, elle devrait être conforme avec ce qui suit : Sortie : 12
VCC, 2 A min., alimentation limitée à conformité CEI 60950-1.
Operating
Temperature
Consumption & Power Input
≥-50ºC PoE: 24.3W (PoE Plus mid-span or switch, 42.5V-57V - 0.57A-0.43A);
AC 24V input: 21.6W [1.76A (PF0.55)];
DC 12V: 21W (1.8A)
