VIVOTEK
14 - User's Manual
Perform the Auto Focus function for best image. However, if you have cascaded cameras,
do this one by one. Do not perform this function simultaneously on multiple cameras
because the motorized lens also consume considerable power, and may cause the last
camera on the line to hang.
IMPORTANT:
LED Denitions
Item LED status Description
LED De`nitions
1 Steady Red Powered and system booting, or network
failed
Red LED off Power off
Green LED off Network is disconnected
2 Steady Red and Green LED blinks every 1
sec.
Connected to network
3 Green LED blinks every 1 sec. and RED
LED blinks consecutively every 0.15 sec.
Upgrading rmware
4 Green and RED blink every 0.15 sec, Green
and RED light on, then blink again.
Restoring defaults
5 RED LED is on, Green LED blinks and RED
LED is constantly on.
Status after a reset (network connected)
Green and RED LEDs are constantly on. Status after a reset (network
disconnected)
