VIVOTEK
86 - User's Manual
Multicast settings for streams: Click the items to display the detailed configuration information.
Select the Always multicast option to enable multicast for video streams.
Unicast video transmission delivers a stream through point-to-point transmission; multicast, on the
other hand, sends a stream to the multicast group address and allows multiple clients to acquire
the stream at the same time by requesting a copy from the multicast group address. Therefore,
enabling multicast can effectively save Internet bandwith.
The ports can be changed to values between 1025 and 65535. The multicast RTP port must be an
even number and the multicast RTCP port number is the multicast RTP port number plus one, and
thus is always odd. When the multicast RTP port changes, the multicast RTCP port will change
accordingly.
If the multicast RTP video ports are incorrectly assigned, the following warning message will be
displayed:
Multicast TTL [1~255]: The multicast TTL (Time To Live) is the value that tells the router the range
a packet can be forwarded.
Initial TTL Scope
0 Restricted to the same host
1 Restricted to the same subnetwork
32 Restricted to the same site
64 Restricted to the same region
128 Restricted to the same continent
255 Unrestricted in scope
IMPORTANT:
The Multicast metadata port is utilized by VIVOTEK VADP modules to transfer video analytics
results, PTZ stream, textual data, and event messages between the camera and the client side
running and observing the video analysis. If your client side computer is located outside the local
network, you may need to open the associated TCP port on routers and rewall.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vivotek IB9371-HT and is the answer not in the manual?

Vivotek IB9371-HT Specifications

General IconGeneral
Built-in HDD-
Flash memory128 MB
Card reader integratedYes
Compatible memory cardsSD, SDHC, SDXC
CertificationCE, LVD, FCC Class A, VCCI, C-Tick, UL
Placement supportedOutdoor
Connectivity technologyWired
Video streamingAdjustable resolution, quality and bitrate Smart Stream II
Total megapixels3 MP
Maximum resolution2048 x 1536 pixels
Video formats supportedH.264, H.265
Image quality adjustmentBrightness, Contrast, Saturation, Sharpness
Video compression formatsH.264, H.265, M-JPEG
Supported graphics resolutions2048 x 1536 (QXGA)
Sensor typeCMOS
Optical sensor size1/2.8 \
Digital zoom48 x
Focal length range3 - 9 mm
Maximum aperture number2.3
Audio input1
Camera shutter speed1/5 - 1/16000 s
Minimum illumination0.001 lx
Form factorBullet
Mounting typeCeiling/wall
Product colorWhite
LED indicatorsPower, Status
Housing materialMetal
Protection featuresVandal proof
International Protection (IP) codeIP66
LED typeIR
Night vision distance30 m
Audio system2-way
Audio formats supportedG.711
Signal-to-Noise Ratio (SNR)60 dB
Browser supportedMozilla Firefox 7~43 (streaming only) Internet Explorer 7/8/9/10/11
Number of users10 user(s)
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.3af, IEEE 802.3at
Ethernet interface typeFast Ethernet
Supported network protocolsIPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, SSL, TLS
InterfaceRJ-45
DC output voltage12
Power source typePoE
Power consumption (max)11 W
Storage temperature (T-T)-20 - 50 °C
Operating temperature (T-T)-10 - 50 °C
Operating relative humidity (H-H)0 - 90 %
Windows operating systems supportedWindows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Weight and Dimensions IconWeight and Dimensions
Height293 mm
Weight1182 g
Diameter88 mm
