EN-3
English
Physical Description
2
Connectors
Ethernet 10/100 RJ45 plug
Audio out (green)
Microphone in (pink)
Power cord socket (black)
General I/O terminal block
Earth
Front panel
IR LED
Lens
Reset button
Status LED
Light sensor
