Power over Ethernet (PoE)
When using a non-PoE switch
Use a PoE power injector (optional) to connect between the Network Camera and
a non-PoE switch.
When using a PoE-enabled switch
The Network Camera is PoE-compliant, allowing transmission of power and data
via single Ethernet cable. See the following illustration to connect the Network
Camera to a PoE-enabled switch via Ethernet cable.
POWER
COLLISION
LINK
RECEIVE
PARTIT
ION
1
2
3
4
5
non-PoE switch
PoE power injector
(optional)
POWER
CO
LLI
SIO
N
LINK
R
ECE
IVE
PARTITION
1
2
3
4
5
PoE switch
