Power over Ethernet (PoE) (IP7151 only)
Power over Ethernet (PoE) (IP7151 only)
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
PoE hub
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
When using a non-PoE hub
Use a PoE power injector (optional) to connect between the camera and a non-
PoE hub.
non-PoE hub
PoE power injector
(optional)
When using a PoE-enabled hub
The camera is PoE-compliant, allowing transmission of power and data via single
Ethernet cable. See the following illustration to connect the camera to a PoE-
enabled hub via Ethernet cable.
