Vivotek IP7151 - General Connection (Without Poe)

EN - 6
General Connection (without PoE)
General Connection (without PoE)
1
. Connect the camera to a hub via Ethernet cable.
2
. Connect the supplied power cable from the camera to a power outlet.
POW ER
COLLISION
LINK
RECEIV E
PARTITION
1
2
3
4
5
1
2
Ethernet hub
4
Network Deployment
