Physical Description
Front Panel
Status LED
Antenna
Lens
Microphone
Light Sensor
Antenna
Back Panel
Mounting Hole
Power Cord
Item LED status Description
LED Denitions
1 Steady Red Powered and system booting, or network failed
2 Blue LED blinks every 0�15 sec� Searching for WPS
3 Green LED blinks every 1 sec� Network connected to an AP
4 Green and RED blink consecutively every
0�15 sec�
Upgrading rmware
5 Steady Blue Operating in camera default AP mode
6 Orange blinks every 0�15 sec� Restoring defaults
7 All LED off Powered off
IR LEDs behind
panel
