VIVOTEK
User's Manual - 151
begintime hh:mm 6/6 Begin time of the weekly schedule.
endtime hh:mm 6/6 End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always on)
action_do_i<0~(ndo-1)
>_enable
0, 1 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1)
>_duration
1~999 6/6 Duration of the digital output trigger in seconds.
action_goto_enable
<product dependent>
<Boolean> 6/6 Enable/disable ptz goto preset position on event
triggered.
action_goto_name
<product dependent>
string[40] 6/6 Specify the preset name that ptz goto on event
triggered.
action_cf_enable <Boolean> 6/6 Enable or disable sending media to SD card.
action_cf_folder string[128] 6/6 Path to store media.
action_cf_media NULL, 0~4 6/6 Index of the attached media.
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
action_cf_backup <Boolean> 6/6 Enable or disable the function that send media to
SD card for backup if network is disconnected.
action_server_i<0~4>_e
nable
0, 1 6/6 Enable or disable this server action.
action_server_i<0~4>_
media
NULL, 0~4 6/6 Index of the attached media.
action_server_i<0~4>_
datefolder
<boolean> 6/6 Enable this to create folders by date, time, and
hour automatically.
7.31 Server setting for event action
Group: server_i<0~4>
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
name string[40] 6/6 Identification of this entry
type email,
ftp,
http,
ns
6/6 Indicate the server type:
“email” = email server
“ftp” = FTP server
“http” = HTTP server
“ns” = network storage
http_url string[128] 6/6 URL of the HTTP server to upload.
