Vivotek IP8352 - Physical Description

VIVOTEK
6 - User's Manual
Physical Description
IR LEDs
Lens
Light Sensor
Zoom Controller
Focus Controller
Reset Button
General I/O
Terminal Block
SD/SDHC Card Slot
General I/O Terminal Block
Gb Ethernet
RJ45 Plug
Power Cord Socket
+ AC 24V +
- AC 24V -
When inserting an SD/SDHC
card, note the orientation of
the contacts�
