Vivotek MS8391-EV - MicroSD Card and Cable Connections

VIVOTEK
User's Manual - 13
M
icro
SD
AC24V- AC24V+ GND audio GND audio Audio out MIC in DI- DI+ DO- DO+ +5V
1
2
3
4
6
5
8
7
10
LAN/PoE
100~240V
AC
ON
OFF
9
GE LAN GE LAN
802.3at
24V 3.5A
PoE
injector
6. Install a MicroSD card. Connect the Ethernet cable and the DI/DO, audio input/output,
and/or the AC 24V input (if preferred).
