172 - User's Manual
URL Command Document for All Series391
37
7.12 Time Shift settings
Group: timeshift, c for n channel products, m is stream number
NAME VA L U E DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable time shift streaming.
c<0~(n-1)>_s<0~(m-1)>_al
low
<boolean> <product
dependent>
4/4 Enable time shift streaming for
specific stream.
7.13 Motion detection settings
Group: motion_c<0~(n-1)> for n channel product
NAME VA L U E DEFAULT SECURITY
(get/set)
DESCRIPTION
enable <boolean> 0 4/4 Enable motion detection.
win_i<0~4>_enable <boolean> 0 4/4 Enable motion window 1~5.
win_i<0~4>_name string[14] <blank> 4/4 Name of motion window 1~5.
win_i<0~4>_left 0 ~ 480 0 4/4 Left coordinate of window
position.
win_i<0~4>_top 0 ~ 180 0 4/4 Top coordinate of window
position.
win_i<0~4>_width 0 ~ 480 0 4/4 Width of motion detection
window.
win_i<0~4>_height 0 ~ 180 0 4/4 Height of motion detection
window.
win_i<0~4>_objsize 0 ~ 100 0 4/4 Percent of motion detection
window.
win_i<0~4>_sensitivity 0 ~ 100 0 4/4 Sensitivity of motion detection
window.
Group: motion_c<0~(n-1)> profile for m profile and n channel product (capability.nmotionprofile >
0)
NAME VA L U E DEFAULT SECURITY
(get/set)
DESCRIPTION
i<0~(m-1)>_enable <boolean> 0 4/4 Enable profile 1 ~ (m-1).
i<0~(m-1)>_policy day,
night,
schedule
night 4/4 The mode which the profile
is applied to.
