VIVOTEK
User's Manual - 163
URL Command Document for All Series391
27
7.8 video input
Group: videoin
NAME
VA L U E
DEFAULT
SECURITY
(get/set)
DESCRIPTION
cmosfreq
50, 60
60
4/4
CMOS frequency.
color
0, 1
1
4/4
0 =>monochrome
1 => color
flip
<boolean>
0
4/4
Flip the image.
mirror
<boolean>
0
4/4
Mirror the image.
ptzstatus
<integer>
2
1/7
A 32-bit integer, each bit can be
set separately as follows:
Bit 0 => Support camera control
function; 0(not support),
1(support)
Bit 1 => Built-in or external
camera; 0 (external), 1(built-in)
Bit 2 => Support pan operation;
0(not support), 1(support)
Bit 3 => Support tilt operation;
0(not support), 1(support)
Bit 4 => Support zoom
operation; 0(not support),
1(support)
Bit 5 => Support focus
operation; 0(not support),
1(support)
text
string[64]
<blank>
1/4
Enclose caption.
imprinttimestamp
<boolean>
0
4/4
Overlay time stamp on video.
URL Command Document for All Series391
28
7.8.1 video input setting per channel
Group: videoin_c<0~(n-1)> for n channel products, and m is stream number
NAME VA L U E DEFAULT SECURITY
(get/set)
DESCRIPTION
whitebalance auto,
manual,
rbgain
auto 4/4 “auto” indicates auto white
balance.
“manual” indicates keep current
value.
“rbgain” indicates using rgain
and gbain.
rgain 0~100 16 4/4 Manual set rgain value of gain
control setting.
bgain 0~100 21 4/4 Manual set bgain value of gain
control setting.
exposurelevel 0~12 6 4/4 Exposure level
minexposure 5~32000 32000 4/4 Minimum exposure time.
maxexposure 5~32000 30 4/4 Maximum exposure time.
maxgain 0~100 100 4/4 Manual set maximum gain
value.
mingain 0~100 0 4/4 Manual set minimum gain
value.
wdrc_mode 0~1 0 4/4 WDR enhanced.
0: off
1: auto
wdrc_strength 0~2 1 4/4 WDR enhanced.
0: low
1: medium
2: high
cmosfreq 50, 60 60 4/4 CMOS frequency.
color 0, 1 1 4/4 0 =>monochrome
1 => color
flip <boolean> 0 4/4 Flip the image.
mirror <boolean> 0 4/4 Mirror the image.
mode 0 ~
"capability_videoi
n_c<n>_nmode"-
0 4/99 Indicate the video mode on
use.
