VIVOTEK
6 - User's Manual
Interface View
RJ45 Ethernet port
Terminal block
MicroSD card slot
Reset button
AC24V-
AC24V+
GND audio
GND audio
Audio out
MIC in
DI-
DI+
DO-
DO+ +5V
Pinouts
