EN - 4
Front panel
Back panel
Activity
Power/MIC
Built-in microphone
Status LED
Lens
Indented reset button
Ethernet 10/100
RJ45 socket
External/Internal
microphone switch
General I/O
terminal block
AV out
Microphone in
Power cord socket
Antenna
(PZ7112 / PZ7122 only)
Physical Description
2
