Vivotek PZ7112 Quick Installation Guide

EN - 6
General Connection (without PoE)
1. If you have external devices such as sensors and alarms, make connections from gen-
eral I/O terminal block.
2. Connect the camera to a switch via a Ethernet cable.
3. Connect the supplied power cable from the camera to a power outlet.
ee
POWER
COLLISION
LINK
RECEIVE
PARTITION
1
2
3
4
5
AV
2
3
Ethernet switch
Network Deployment
4
1: Power
2: Digital output
3: Digital input
4: Ground
1

Vivotek PZ7112 Specifications

General

Brand	Vivotek
Model	PZ7112
Category	Security Camera
Language	English
