VIVOTEK
User's Manual - 19
Pan: Click this button to start the auto pan� When the current position is Home or on the left side of
Home, the camera starts panning from the current position to the left-most position, then to the right-
most position, and nally backward to the original position. When the current position is on the right side
of Home, the camera starts panning from the current position to the right-most position, then to the left-
most position, and nally backward to the original position.
Stop: Click this button to stop the Auto Pan and Auto Patrol functions�
Patrol: Once the Administrator has determined the list of preset positions, click this button to command
the camera to patrol among those positions on the Patrol List� For more information, please refer to
Camera control of Conguration on page 60�
Pan /Tilt speed: Adjust the speed of pan/ tilt�
Conguration Area
Client Settings: Click this button to access the client settings page� For more information, please refer to
Client Settings on page 22�
Conguration: Click this button to access the conguration page of the Network Camera. It is suggested
that a password be applied to the Network Camera so that only the administrator can configure the
Network Camera� For more information, please refer to Conguration on page 24�
Language: Click this button to choose a language for the user interface� Language options are available
in: English, Deutsch, Español, Français, Italiano,
日本語
, Português,
簡体中文
, and
繁體中文
�
Live Video Window
■ The following window is displayed when the video mode is set to MPEG-4:
Pan speed Tilt speed
-5 -5 Slower
Faster
-4 -4
-3 -3
-2 -2
-1 -1
0 0
1 1
2 2
3 3
4 4
5 5
Video and Audio Control Buttons
Drop-down List of Preset Positions
MPEG-4 Protocol and Media Options
Video Title
Time
Title and Time
Video 13:3 2:09 2008/12/01
