130 - User's Manual
weekday 0~127 6/6 Indicate which weekday is scheduled.
One bit represents one weekday.
bit0 (LSB) = Saturday
bit1 = Friday
bit2 = Thursday
bit3 = Wednesday
bit4 = Tuesday
bit5 = Monday
bit6 = Sunday
For example, to detect events on Friday and
Sunday, set weekday as 66.
begintime hh:mm 6/6 Begin time of the weekly schedule.
endtime hh:mm 6/6 End time of the weekly schedule.
(00:00 ~ 24:00 sets schedule as always on)
action_do_i<0~(ndo-1)
>_enable
0, 1 6/6 Enable or disable trigger digital output.
action_do_i<0~(ndo-1)
>_duration
1~999 6/6 Duration of the digital output trigger in seconds.
action_cf_enable 0. 1 6/6 Enable media write on CF.
action_cf_folder string[128] 6/6 Path to store media.
action_cf_media NULL, 0~4 6/6 Index of the attached media.
action_cf_datefolder <boolean> 6/6 Enable this to create folders by date, time, and hour
automatically.
action_server_i<0~4>_e
nable
0, 1 6/6 Enable or disable this server action.
The default value is 0.
action_server_i<0~4>_
media
NULL, 0~4 6/6 Index of the attached media.
action_server_i<0~4>_
datefolder
<boolean> 6/6 Enable this to create folders by date, time, and hour
automatically.
action_goto_enable <Boolean> 6/6 Enable/disable ptz goto preset on event triggered.
action_goto_name string[40] 6/6 Preset name that ptz goto on event triggered.
Group: server_i<0~4>
PARAMETER VALUE SECURITY
(get/set)
DESCRIPTION
name string[40] 6/6 Identification of this entry
